it is designed for plastic, films, glass, lcd panel, touch screen and other transparent and semi-transparent materials color, haze and transmittance measurement.

instrument introduction
1. conform to astm and iso standard. 3 kinds of light sources a,c and d65 for haze measurement.

2. it can realize transmittance compensation measurement which can provide higher accuracy test result.

3. open measurement area, no limit on sample size. vertical measurement is also available.

4. different fixtures to meet the measurement requirement for sheet material and liquid in different shapes.

5. instrument is with haze and transmittance measurement software.

instrument details

liquid measurement sheet material measurement

cap for compensation port 0% calibration cap

type	color and haze cs-720
light source	cie-a,cie-c,cie-d65 chromaticity value:a,c,d50,d55,d65,d75,f1,f2,f3,f4,f5,f6,f7,f8,f9,f10,f11,f12,cmf,u30,dlf,nbf,tl83,tl84
standards	astm d1003/d1044,iso13468/iso14782, cie no.15,iso 7724/1,astm e1164,din 5033 teil7, jis z8722 condition c
parameters	haze,transmittance(t),spectral transmittance, whiteness index (astm e313-00,astm e313-73锛孋ie/iso锛孉atcc锛孒unter锛孴aube berger stensby) yellowness index (astm d1925锛孉stm e313-00锛孉stm e313-73) tint(astm e313-00),metamerism index,milm apha,pt-co,gardner,color difference(δeab,δech,δeuv,δecmc(2:1),δecmc(1:1),δe94,δe*00)
spectral response	cie luminosity function y
wavelength	400-700nm
wavelength interval	10nm
geometry	0/d
measurement area/sample port	16.5mm/21mm
measurement range	0-100%
haze resolution	0.01
haze repeatability	≤0.1
sample size	thickness≤150mm
display	5 inch tftlcd screen
memory	20000 values
interface	usb
power	220v
working temperature	10-40鈩?/span>
storage temperature	0-50鈩?/span>
size (lxwxh)	598mmx247mmx366mm
standard accessory	pc software (color qc)
optional	measurement fixture, haze standard film

1. one year warranty.
