cs-286
- cs-286
-
spectral colorimeter is the colorimeter which adopts the theory of spectrophotometer. it is widely used for plastic, printing, paint, ink, textile, dyeing and other industries for color management. it could measure the target l*a*b, l*c*h and the sample 鈻矱 and 鈻矻ab value.
part one. instrument introduction
1. spectral colorimeter : the highest precision colorimeter
2.adoptsspectral measurement working theory which greatly improve the accuracy of colorimeter
3. patented technology guarantees the measurement stability
4. obtain national metrology certification
5. ergonomic design
instrument girth radian designs according to human palm so we could test data for a long time. superior leather design increases the friction in case of fingers sliding.
6. mass storage memory:it could save 100 pcs targets and 200 pcs samples.
1. spectral colorimeter : the highest precision colorimeter
2.adoptsspectral measurement working theory which greatly improve the accuracy of colorimeter
3. patented technology guarantees the measurement stability
4. obtain national metrology certification
5. ergonomic design
instrument girth radian designs according to human palm so we could test data for a long time. superior leather design increases the friction in case of fingers sliding.
6. mass storage memory:it could save 100 pcs targets and 200 pcs samples.
| type | cs-286 |
| illumination |
di/8(diffused illumination, 8 degree viewing) (conform to cie no.15銆両so 7724/1銆丄stm e1164銆丏in 5033 teil7銆丣is z8722 condition c standard锛?/td> |
| size of integrating sphere | φ40mm, avian diffused reflection surface coating |
| illumination light source | cled |
| sensor | array sensor |
| wavelength | 400-700nm |
| spectrum resolution | 10nm |
| measurement time | 2s |
| measurement aperture | 11mm,optional 4mm,6mm,15mm |
| repeatability | standard deviation δe*ab 0.08(when a white calibration plate is measured 30 x at 10-second intervals after calibration) |
| observe angles | 2° and 10° |
| light source | a,c,d50,d55,d65,d75,f1,f2,f3,f4,f5,f6,f7,f8,f9,f10,f11,f12,dlf,tl83,tl84,nbf,u30,cwf锛孶35 |
| display | chromaticity value锛圠*a*b锛孡*c*h锛? delta e value, pass/fail, color tendency, average, generate test report, spectrum reflectance figure /data |
| with camera to see the measurement area, spectrum reflectance figure /data, manual input target data | |
| color difference formula | δe*ab,δe*ch,δe*uv,δe*cmc(2:1),δe*cmc(1:1),δe*94,δe*00 |
| color space | cie-l*a*b,l*c*h, l*u*v ,xyz,yxy, reflectance |
| other | wi(astm e313-10,astm e313-73,cie/iso,aatcc,hunter,taube berger锛孏anz锛孲tensby) yi(astm d1925锛孉stm e313-00,astm e313-73) |
|
metameric index ,staining fastness ,color fastness |
|
| data storage | 20000samples |
| light source lifetime | 5 years, 1.5 million times |
| other function | camera view, input color swatches |
| screen | panchromatic true color screen |
| language | chinese and english |
| interface | usb2.0 |
| operating temperature | 5~45鈩? relative humidity 80% or below( at 35°c ),no condensation |
| storage temperature range | -25鈩僼o 55鈩冿紝relative humidity 80% or below(at 35°c ),no condensation |
| power | rechargeable lithium battery 8.4v/2000mah, adaptor dc12v |
| size | 77×86×210mm |
| weight | about 550g |
| standard accessories | adapter, operating manual, color management software, drive software, electronic manual, color management guide, usb cable, black/white calibration tube, protective cover, portable bag, electronic color charts |
| optional | micro printer |
| color matching system | not matched |
| uv light source | without |
part two. technology advantages
1).uses cleds light source – spectrally balanced led light source (patent no. : zl2013107548347)
led light source that has balanced intensity across visible spectrum avoids the spectral deficiency in certain parts of the spectrum in common white leds, which guarantees the speed and accuracy of the measurement results. this research has been published in national leading optical journal chinese optics letter.
2).etc-every test calibration technology (patent no. : zl20130373360.1)
currently, most instruments use standard white boards for calibration. when white board is damaged, the instrument’s accuracy or precision will no longer be guaranteed. in chnspec’s spectrophotometers, it uses innovative etc(every test calibration); standard white board is included in the optical system, and therefore has reliable accuracy and repeatability in every measurement.
3).automatic gloss compensation technology (patent no. :zl201310511357.1)
different gloss or different instrument’s light source or observation conditions will largely affect the color measurement. the automatic gloss compensation technology guarantees the accuracy of color measurement data for surfaces of different gloss. this research is published in international leading journal optik.
1).uses cleds light source – spectrally balanced led light source (patent no. : zl2013107548347)
led light source that has balanced intensity across visible spectrum avoids the spectral deficiency in certain parts of the spectrum in common white leds, which guarantees the speed and accuracy of the measurement results. this research has been published in national leading optical journal chinese optics letter.
2).etc-every test calibration technology (patent no. : zl20130373360.1)
currently, most instruments use standard white boards for calibration. when white board is damaged, the instrument’s accuracy or precision will no longer be guaranteed. in chnspec’s spectrophotometers, it uses innovative etc(every test calibration); standard white board is included in the optical system, and therefore has reliable accuracy and repeatability in every measurement.
3).automatic gloss compensation technology (patent no. :zl201310511357.1)
different gloss or different instrument’s light source or observation conditions will largely affect the color measurement. the automatic gloss compensation technology guarantees the accuracy of color measurement data for surfaces of different gloss. this research is published in international leading journal optik.
4).innovative light splitting scs optical engine (patent no. : zl201210337619.2)
adopt innovative single-grating-dual-light-paths light splitting system: scs optical engine , creates the best measurement repeatability for portable spectrophotometers in the industry, and guaranteed accurate measurement of surface color of materials.
part three. instrument details
part six. guarantee
1).longest guarantee time
a. three years guarantee time.
b. if testing data is not correct, we can do refund.
c. we will provide testing report for every device to assure the authority of the data and it will save the calibration cost for 1 year.
1).longest guarantee time
a. three years guarantee time.
b. if testing data is not correct, we can do refund.
c. we will provide testing report for every device to assure the authority of the data and it will save the calibration cost for 1 year.
-
