cs-260
- cs-260
-
introduction
cs-260 color card reading colorimeter can read the color samples and display the most similar color card number. it’s widely used in printing, printing and dyeing, clothing, decoration, design, construction, home furnishing, food industry etc..
cs-260 color card reading colorimeter also has chromatic instrument function, it can test the surface of l, a, b, l*c*h, e*ab, xyz, relative rgb values, hunter whiteness, ganz whiteness, yi equivalent and distinguish color aberration easily.
introduction
cs-260 color card reading colorimeter can read the color samples and display the most similar color card number. it’s widely used in printing, printing and dyeing, clothing, decoration, design, construction, home furnishing, food industry etc..
cs-260 color card reading colorimeter also has chromatic instrument function, it can test the surface of l, a, b, l*c*h, e*ab, xyz, relative rgb values, hunter whiteness, ganz whiteness, yi equivalent and distinguish color aberration easily.
cs-260 color card reading colorimeter can read the color samples and display the most similar color card number. it’s widely used in printing, printing and dyeing, clothing, decoration, design, construction, home furnishing, food industry etc..
cs-260 color card reading colorimeter also has chromatic instrument function, it can test the surface of l, a, b, l*c*h, e*ab, xyz, relative rgb values, hunter whiteness, ganz whiteness, yi equivalent and distinguish color aberration easily.
technical parameters
| color measurement | color card |
| illumination systen | 8°/d锛?°/diffused illumination锛夛紝specular component included锛圫ci锛?/td> |
| display modes |
colorimetric values: l*a*b锛孡*c*h锛屸柍e*ab锛孹yz锛宺elative rgb values; color difference values: 鈻?l*a*b)锛屸柍(l*c*h); whiteness values:hunter whiteness,ganz whiteness yellowness value:yi |
| measuring caliber | about 8mm |
| measuring conditions | cie 10° standard observer; cie d65 light source |
| measuring range | l*锛?-100 |
| repeatability | standard deviation within鈻矱*ab*锛?.08(condition: measure the white calibration board 30 times for average |
| storage | 100 sets of standard samples; up to 100 under each standard sample |
| measuring time | about 0.5 seconds |
| measuring light source | halogen lamp |
| interface languages | chinese,english |
| power source | four aa1.5v alkaline battery or nickel-metal hydride batterys;exclusive dc5v adapter |
| port | usb 2.0, printer |
| weight | 550g |
| size | 77×86×210mm |
characteristic
1銆乀est your sample, you can get the closest color card number.
2銆丄pply to many different types the color card.
3銆丏isplay precision 0.01
4銆丷epeatability precision δe standard deviation 0.08
5銆乀est parameters:
colorimetric values: l*a*b锛孡*c*h锛屸柍e*ab锛孹yz锛宺elative rgb values;
color difference values: 鈻?l*a*b)锛屸柍(l*c*h);
whiteness values:hunter whiteness, ganz whiteness
yellowness value:yi
6銆丼torage: 100 sets of standard samples; up to 100 under each standard sample.
7銆?.4-inch-wide color screen.
1銆乀est your sample, you can get the closest color card number.
2銆丄pply to many different types the color card.
3銆丏isplay precision 0.01
4銆丷epeatability precision δe standard deviation 0.08
5銆乀est parameters:
colorimetric values: l*a*b锛孡*c*h锛屸柍e*ab锛孹yz锛宺elative rgb values;
color difference values: 鈻?l*a*b)锛屸柍(l*c*h);
whiteness values:hunter whiteness, ganz whiteness
yellowness value:yi
6銆丼torage: 100 sets of standard samples; up to 100 under each standard sample.
7銆?.4-inch-wide color screen.
-
